HOGSTER-R 2.0-8.0x35mm and 1.4-5.6x25mm

Thermal scopes
> HOGSTER-R 2.0-8.0x35mm and 1.4-5.6x25mm

Instruction manual
(BE43035, BE43025)

Features

Superior for hogs and predator control at medium- and long-range distances

Switchable image polarity: White Hot / Black Hot / Red Hot / Colored Hot
Picture-in-Picture function-  2X magnified image on the top of the display
Rangefinder function to estimate distance to the animals of known size
Manual control of the image sharpness and screen brightness
Ability to save up to 4 groups of zeroing calibration data
Four reticle patterns with 4 color options for each pattern
Option to power by rechargeable 3.7V accumulators

Automatic shatter based thermal VOx core

Precise lens focusing mechanism
External power supply via a USB port
Battery status indicator
Standby mode
Video Out


Customer review

Thought I would send you a photo of the Hogster mounted up on my AR-Pistol. Thanks Again.

Derek, USA.

The best affordable thermal money can buy.

Estevan Garcia, USA

I shot the HOGSTER-R yesterday on my 308 AR10. The optic did excellent ! Focus was rock solid throughout the string of fire , no shutdowns or freezes , zeroing tracked well. I’m a happy customer.

Ben, DFW, USA.

Your company has demonstrated exceptional engineering skills by optimizing components and technology, achieving impressive results despite having nominally modest specs compared to your competitor.

Andrey, Houston, USA.


About

HOGSTER R™ VOx 384x288 Thermal Weapon Sights are aimed at the growing feral hog market. The sight  is exceptionally lightweight, compact and .308 Cal. tested. HOGSTER R™ comes with a tactical quick release (QR) mount that makes the mounting on any type of rifle, equipped with the Weaver rail, quick and easy. HOGSTER R™ compactness makes it suitable for use as a handheld imager for scouting purposes.

The sight is built with the superb Germanium optics that is paired with an advanced Vanadium Oxide (VOx) thermal core and proprietary electronics. HOGSTER R™ features an intuitive, user-friendly menu to customize settings to the shooter’s needs without disengaging from the target, including MIL-Dot and Crosshair reticles along with White, Black and Colored image polarization.

The scope is nitrogen-purged, is water-, dust- and shock-proof and is action ready in any environment or light conditions, including conditions when the environmental obscurants such as smoke, dust, haze, are present. HOGSTER R™ is suitable for use in colder temperatures thanks to the unique built  retaining its own heat and keeping the cold sensitive elements warm, virtually making it a great universal choice for any demanding user.

Specifications

Product Modification

HOGSTER-R

Product SKU#

BE43025

BE43035

Optical Magnification, x

1.4x

2.0x

Digit Multiplication, X

2X, 3X, 4X

Objective lens system

25mmF/1.1

35mmF/1.1

Angular FOV at 1.0x (horizontal x vertical), degree

14.9° x 11.2°

10.7° x 8°

Eye relief, mm

40

Focus range, m

0.5 to infinity

Diopter Adjustment, D (hand held mode only)

-5: +5

Reticle W/E adjustment value at a distance of 100m (110yds)

0.8"/2.04cm increment per pxl

Core resolution, pxl

384x288

Pixel pitch, µm

17

Image refresh rate, Hz

50

Thermal Sensitivity (NETD), mK

<50

Display type and resolution, pxl

LCOS 1280x960

Start-up time, min., sec.

5

Animal type and size (in Length &  Height), approx., ft²

Hog
L16 & H9

Coyote
L5 & H2

Hog
L16 & H9

Coyote
L5 & H2

Detection, approx., yds / m

600 /550

460 /420

800 /750

660/600

Recognition, approx., yds / m

225 /200

160 /145

300 /275

200 /185

Dimensions with QR mount, in / mm

7.0"x2. 83"x2. 36" / 180x72x60

7.68"x2. 83"x2. 36" / 195x72x60

Weight,  approx., oz/g

16.44 / 466

17.14 / 486

Power supply

3V CR123 (two) or 3.7V rechargeable (two) or 5V Type C USB port

Estimated battery life, hour

up to 4

Operating temperature, typical, °F/°С

-14° to +122° / -25° to +50°

Water intrusion

IP67

Humidity, %

up to 98%

In Box
  • HOGSTER R VOx 384x288 Thermal sight
  • Video-out or external power supply Type C USB cable
  • Weapon Mount
  • Two Lithium CR123 batteries
  • Front lens protective cap
  • Eye piece rubber eye guard
  • Soft Carrying Case
  • Lens Cleaning Cloth
  • Instructions manual
  • Video-out or external power supply Type C USB cable

OPTIONAL ACCESSORIES (sold separately)

  • Hard Carrying Case
  • Bluetooth Wireless Remote Control


WARNING! Cancer and Reproductive Harm - www.p65warnings.ca.gov
